Dia 75mm

Overview

Basic Info.

Model NO.	UHP HP RP 75-700mm
Specification	UHP HP RP 75mm-700mm
Trademark	Hengqiang Carbon
Origin	Hebei, Handan
HS Code	8545110000
Production Capacity	50000tons Per Year

Product Description

Company Profile

Graphite Electrode Factrory.

20 Years industrial experience.Rich experience in Exporting by vessel, train and railway wagon.Supply graphite electrodes RP/HP/UHP D100-D700mm Strict quality control from raw materials to finished products
Advanced production technology and strong technical force

Customers VisitingExcellent sales at home and abroad, export to more than 20 countries and areas like Europe, the Middle East, Southeast Asia, the Americas, Africa etc..Product DescriptionPRODUCT FEATURE
Has good electrical conductivity Strong thermal shock resistance
High mechanical strength Low consumption
Technical Data:

Item	Classification	Unit	Nominal Diameter (mm)
			RP	HP	UHP
			75-700	200-600	300-700
Electrical resistivity (≯)	PoleNipple	μΩm	8.56.5	7.05.5	5.54.0
Bending strength (≮)	PoleNipple	Mpa	7.015.0	10.016.0	11.020.0
Young's modulus (≯)	PoleNipple	Gpa	9.314.0	14.018.0	14.022.0
Bulk density (≮)	PoleNipple	g/cm3	1.581.70	1.651.72	1.681.80
Thermal expansion coefficient (≯)(100ºC-600ºC) CTE	PoleNipple	×10-6/ºC	2.92.8	2.21.6	1.41.2
Ash content (≯)		%	0.5	0.3	0.2

Certifications

Obtained ISO9001 quality system certification.

Packaging & Shipping
Packing: Wooden cases with pallet and steel belt fastening, make sure the packing is suitable to sea and train transportation.
